Ucs (4) 9124 - 9128 | TrainsDepot.org

Source: Per Topp Nielsen - toppsmagic.dk

Source: Dr2005 - transport-in-comun.ro

Ucs (4) 9124 - 9128

UIC / EVN numbering: 42 53 9124 / 41 53 9125 / 25 53 9126 / 42 53 9126 / 42 53 9127 / 42 53 9128

Vehicle type: freight wagon

Registration country: Romania

Railway companies: CFR - Caile Ferate Române CFR Marfa / CFR Marfă - Societatea Națională de Transport Feroviar de Marfă (CFR Marfă)

Hide technical details

Length over buffers (mm):

9'000 mm

Width (mm):

2'810 mm

Height (mm | over lowered pantograph):

4'248 mm

Wheelbase (mm | rigid / total):

5'000 mm

Minimum radius of curvature on open stretches (m):

150 m

Minimum radius of curvature on switching sections (m):

75 m

Tare weight (t):

12,4 t

Maximum load weight (t):

28 t

Wheel diameter (x'xxx,xx | mm | new / worn):

1'000 mm

Maximum speed (km/h):

120 km/h

Braking system (vacuum brakes / air brakes / electropneumatic brakes / electronically controlled pneumatic brakes / electric brakes - tread (clasp) brakes / axle-mounted disk brakes / wheel-mounted disk brakes / dynamic brakes / regenerative brakes / rail brakes):

KE-GP

Maximum load volume (m³):

25 m³

Display registration numbers

Vehicle's history

Add content

Report an error?

1975

The units from this series are built between 1975 and 1980.

Sources: http://www.cfrmarfa.com/index2.php?option=com_content&view=article&id=140:ucs&catid=47

Do you have additional informations regarding this vehicle?

Help us writing the history of Ucs (4) 9124 - 9128! Your knowledge is precious for us and the entire community, do not hesitate to share your facts, photos or videos:

Add new timeline entry

Add photos

Add videos

Latest update on the 20th of June 2021 at 19:29

Contributor(s): Tudor C.
