BC^AM/_MOT

Also known as: Sentinel-Cammell 4-axles

Vehicle type: Steam railcar

Registration country: Romania

Railway companies: CFR - Caile Ferate Române

Hide technical details

In service:

from 1932

Length over buffers (mm):

19'100 mm

Wheelbase (distance between bogies centers) (mm):

12'292 mm

Tare weight (t):

31,955 t

Service weight (t):

35,460 t

Number of driven axles:

Engine:

6-cylinder steam engine

Power output (x'xxx kW / x'xxx hp):

100 hp

Bogie wheelbase (mm):

2'286 mm*
*driven bogie
1'981 mm*
*carrier bogie

Wheel diameter (x'xxx,xx | mm | new / worn):

955 mm

Maximum speed (km/h):

90 km/h*
*70 km/h maximum permissible speed on the Romanian Railways network

Total number of seats (1st class seats / 2nd class seats / 3rd class seats / folding seats):

55x seats (16x 2nd class seats and 39x 3rd class seats)

Display registration numbers

Vehicle's history

Add content

Report an error?

1932

A total of 6x units of this type are delivered. They are initially assigned to Craiova, Dej and Bacau depots for the following railway lines:
Craiova - Filiasi - Targu Jiu;
Craiova - Calafat;
Dej - Cluj;
Bacau - Piatra-Neamt.
