Fas E74

Also known as: Fas E83/E84

UIC / EVN numbering: 31 87 673 6 / 31 87 673 7

Vehicle type: freight wagon

Registration country: France

Railway companies: SNCF - Société Nationale des Chemins de Fer français

Hide technical details

In service:

from 1978

Era:

IV - V

Gauge:

Standard gauge (1'435 mm)

Length over buffers (mm):

15'110 mm

Width (mm):

3'060 mm

Height (mm | over lowered pantograph):

3'385 mm

Wheelbase (distance between bogies centers) (mm):

10'070 mm

Minimum radius of curvature (m):

35 m

Tare weight (t):

22,6 t

Maximum weight (t):

80 t

Maximum load weight (t):

57 t

Maximum speed (km/h):

100 km/h*
*loaded
120 km/h*
*empty

Floor surface (m²):

37,80 m²

Maximum load volume (m³):

76,50 m³

Display registration numbers

Vehicle's history

Add content

Report an error?

1978

The units from this series are built between 1978 and 1980 and are initially designated as Fas E83/E84.

Units Fas E83 have a steel floor while units Fas E84 have a wooden floor.

Sources: Ferrovissime n° 93 - mai/juin 2018

1991

105x units from this series are converted to Tams T14 freight wagons:
- 45x Fas E83 units are converted in 1991;
- 60x Fas E84 units are converted in 1992.

Sources: Ferrovissime n° 93 - mai/juin 2018

1994

From 1994, these units are designated as Fas E74 (units derived from Fas E84 are equipped with a steel floor).

Sources: Ferrovissime n° 93 - mai/juin 2018
