Tams T14

UIC / EVN numbering: 31 87 580 7 / 31 87 080 7 / 33 87 080 7

Vehicle type: freight wagon

Registration country: France

Railway companies: SNCF - Société Nationale des Chemins de Fer français

Hide technical details

In service:

from 1991

Era:

Gauge:

Standard gauge (1'435 mm)

Length over buffers (mm):

15'110 mm

Width (mm):

3'148 mm

Height (mm | over lowered pantograph):

3'615 mm

Wheelbase (distance between bogies centers) (mm):

10'070 mm

Minimum radius of curvature (m):

35 m

Tare weight (t):

25,85 t

Maximum weight (t):

80 t

Maximum load weight (t):

54,1 t (54,7 t)

Maximum speed (km/h):

100 km/h*
*loaded
120 km/h*
*empty

Floor surface (m²):

37,80 m²

Maximum load volume (m³):

76,50 m³

Display registration numbers

Vehicle's history

Add content

Report an error?

1991

The 105x units from this series are converted from Fas E83/E84 freight wagons:
- 45x units are converted in 1991 from Fas E83 units, equipped with a steel floor;
- 60x units are converted in 1992 from Fas E84 units, equipped with a wooden floor.

These wagons are equipped with a retractable roof mechanism made of synthetic material. The 60x units converted from Fas E84 units also receive a new steel floor.

These units are initially registered in the range 31 87 580 7 300 - 499, despite the fact there are only 105x units in this series. Soon after, following a numbering change in the UIC classification, these units will be renumbered in the 31 87 080 7 300 - 499 range.

Initially, the T14 units are intended for the transport of certain scrap metals sheltered from rain and snow to prevent their oxidation.

Sources: Ferrovissime n° 93 - mai/juin 2018

2007/08

During this period, the first 4x units of the series are rented to Hendaye-Manutention and are the first to receive operational code 33 and thus are registered 33 87 080 7 300 - 303.

Sources: Ferrovissime n° 93 - mai/juin 2018

2011

All units are transferred to Ermewa group where they are registered Tams 33 87 080 7 300 - 499.

Sources: Ferrovissime n° 93 - mai/juin 2018
