Hide technical details
Gauge:
Standard gauge (1'435 mm)
Length over buffers (mm):
16'000 mm
Height (mm | over lowered pantograph):
4'130 mm
Tare weight (t):
24,5 t
Maximum load weight (t):
67 t
Bogies:
Y25 CsII(DB)
Maximum speed (km/h):
120 km/h*
*empty
100 km/h*
*loaded
Braking system (vacuum brakes / air brakes / electropneumatic brakes / electronically controlled pneumatic brakes / electric brakes - tread (clasp) brakes / axle-mounted disk brakes / wheel-mounted disk brakes / dynamic brakes / regenerative brakes / rail brakes):
KE-GP
