Numérotation UIC / EVN:
50 53 22-96Type de véhicule:
Pays d'immatriculation:
Compagnies ferroviaires:
Length over the buffers: 26 400 mm
Gauge: 1 435 mm;
Bogies type: GP 200
Circulation speed: 200 Km/h
Brake type: KE-GPR-Mg(D)
Sanitary installations: 2 toilette cabins provided with vacuuming
units and sewage tanks for 22.96 and 30.76 series
Access doors: pivoting with electro-pneumatic closing, opening and
blocking for speed more than 5 Km/h
Number of seats: 60 seats (4 or 6 compartments and 3 saloons)
Power supply: static mono-voltage power supply, according to UIC
550:
– Input Voltage: 1500 V/50 Hz;
– Output Voltage: 1500 V/50 Hz; 3×400 V/50 Hz; 230 V/50 Hz and 24
Vcc;
Air conditioning (ventilation, heating, cooling) – complex, totally
automatic, with ecological Freon type R134a, according to UIC
553;
Passenger Information: displays located outside and inside the
wagons to indicate the route via GPS system.
2009
Sources: https://www.vagonweb.cz/popisy/popisy.php?k=CFR&z=a&p=v&lang=en
