10584-92 101 - 106 | TrainsDepot.org

ARDmh¹⁰⁵84-92 101 - 106

Also known as: ARDmh¹⁰⁵ 84-90 101 - 103

UIC / EVN numbering: 61 80 84-90 / 61 80 84-70

Vehicle type: restaurant / bar / buffet coach

Registration country: Germany

Railway companies: DB - Deutsche Bundesbahn

Hide technical details

In service:

from 1969

Built by:

Hansa Wagon construction

Length over buffers (mm):

27'500 mm

Height (mm | over lowered pantograph):

4'050 mm

Wheelbase (distance between bogies centers) (mm):

19'500 mm

Tare weight (t):

42,8 t

Bogies:

Minden-Deutz 34 (340) / 36 (363)

Bogie wheelbase (mm):

2'500 mm

Maximum speed (km/h):

140 km/h
200 km/h

Braking system (vacuum brakes / air brakes / electropneumatic brakes / electronically controlled pneumatic brakes / electric brakes - tread (clasp) brakes / axle-mounted disk brakes / wheel-mounted disk brakes / dynamic brakes / regenerative brakes / rail brakes):

-R- KE-GPR-Mg (D)

Compartments (compartments / attendant compartment):

Number of seats / compartment (1st class seats / 2nd class seats / 3rd class seats / folding seats):

6x 1st class seats

Total number of seats (1st class seats / 2nd class seats / 3rd class seats / folding seats):

18x seats*
*dining area
11x seats*
*bar area

Display registration numbers

Vehicle's history

Add content

Report an error?

1969

Similar to ARDmh¹⁰⁵ 84-80 101 - 108 coaches, 3x units from this series are built by Hansa in 1969.

These units are registered ARDmh¹⁰⁵ 84-70 101 - 103.

Sources: http://www.dbtrains.com/en/coaches/epochIII/rheingold-tee/ardm

Do you have additional informations regarding this vehicle?

Help us writing the history of ARDmh¹⁰⁵84-92 101 - 106! Your knowledge is precious for us and the entire community, do not hesitate to share your facts, photos or videos:

Add new timeline entry

Add photos

Add videos

Latest update on the 31st of May 2020 at 11:15

Contributor(s): Tudor C.
