Bp
Also known as:
Bai
UIC / EVN numbering:
50 54 20-1150 54 20-1250 54 29-22Vehicle type:
Registration country:
Railway companies:
In service:
from 1960
Era:
III - IV
Built by:
Gauge:
Standard gauge (1'435 mm)
Length over buffers (mm):
23'500 mm
Width (mm):
2'900 mm
Height (mm | over lowered pantograph):
4'060 mm
Wheelbase (distance between bogies centers) (mm):
16'200 mm
Tare weight (t):
34 t
Bogies:
JHY (Pennsylvania)
Maximum speed (km/h):
120 km/h
Train heating (electric / steam):
steam and electric
1960
The units from this series are built between 1960 and 1962.
Initially registered Bai 4-4110 - 4-4995, they will later receive
UIC registration numbers 50 54 20-11 458 - 999 and 50 54 20-12 000
- 336.
Sources: https://www.parostroj.net/katalog/ov/formular.php3?ind=51
Do you have additional informations regarding this vehicle?
Help us writing the history of Bp! Your knowledge is precious for us and the entire community, do not hesitate to share your facts, photos or videos:
Latest update on the 10th of January 2024 at 22:37
Contributor(s): Tudor C.
